Avant 800 Series Mini Loader | Avant Equipment
800 Series The largest and most powerful
800 Series The largest and most powerful Avant loader - powerful lift capacity and high lift height.
The Avant 800 Series is the flagship of the Avant loader range – offering the highest lift height and greatest capacity of any model. With a 1.9 tonne lift capacity, it easily handles heavy loads such as bricks or pavers, moves and loads heavy logs in the chipper, and loads trucks from one side without repositioning.
Despite its power, the 800 Series remains compact enough to tow on a standard car trailer and operate in tight access areas. The standard ROPS/FOPS cab ensures safety, while the optional enclosed GT cab adds air conditioning, low noise level, vibration isolation, and excellent visibility for all day ergonomic comfort.
Customise your 800 Series with features like Bluetooth, an air suspension seat and more – making it the ultimate compact loader for demanding jobs.
- Lift capacity 1,900 kg
- Lift height 3.5 m
- Engine power 49-57 hp
- Drive speed 0-30 km/h
- Large 17" wheels as standard
- Cab with air conditioning available
- Optional GT Cab available - vibration-insulated and lower noise
- Extended reach with a telescopic boom
- Optidrive™ drive circuit gives more power for the drive and hydraulic attachments.
- Avant quick attach system as standard
- Over 200 attachments available
The mini loader that will become
your best friend.
Secure
The Avant 800 Series mini loader combines stability and safety with a low centre of gravity and clear operator view. Its robust non-swinging articulation and advanced 4×4 system deliver maximum traction and balance.
Standard ROPS/FOPS cabs provide safety, with optional enclosed cabs for extra comfort and protection.
Telescopic boom
Avant mini loaders are engineered for maximum performance in a compact design. Despite their small size, the reach and lift height are never compromised.
Equipped with a powerful telescopic boom, each Avant mini loader delivers impressive outreach and lifting capacity for its size. The boom can be retracted for lifting heavy loads and fully extended for exceptional reach and height.
Thanks to the telescopic boom’s versatility, operators can easily load trailers from one side while maintaining excellent all-round visibility and control — improving both efficiency and safety on site.
Versatile
Avant attachments are specially designed to work seamlessly with Avant mini loaders, ensuring the perfect balance of power, size, and performance. This precise compatibility delivers outstanding efficiency and productivity on every job.
With a wide range of attachments and options — including four cab types, extra work lights, and the Opticontrol™ system — Avant compact loaders can be used all year round. From winter maintenance to summer landscaping, they’re built for every season.
Avant’s hydraulic multi-connector makes changing attachments quick and effortless. It allows one-handed connection or disconnection, even under pressure or in freezing conditions, with no leaks and no risk of incorrect coupling.
Avant 4x4
All Avant mini loaders feature a robust hydrostatic drive system, with a powerful hydraulic motor on each wheel for smooth, responsive performance. The system includes advanced traction control valves to optimise grip in all conditions.
This intelligent design allows the left and right wheels to rotate at different speeds, reducing tyre wear on hard surfaces and preventing scuffing on soft or delicate ground.
The integrated 4×4 hydraulic differential lock balances oil flow between the wheel motors, delivering superior traction and stability on slippery or uneven terrain.
Technical Specifications
Lift Capacity 1900 kg
Engine Power 49 hp
Lift Height 3.5 m
Speed 26 km/h
Specifications
| Length | 3395 mm |
|---|---|
| Width (with standard wheels) | 1490 mm |
| Height (with standard wheels) | 2200 mm |
| Weight | 2560 kg |
| Standard wheels | 380/55-17” TR |
| Transmission, drive | hydrostatic |
| Pulling force max. | 1500 kp |
| Drive speed max. | 24 km/h |
| Auxiliary hydraulics | 70 l/min 225 bar |
| Turning radius inside/outside | 1370 mm / 2990 mm |
| Lifting height to pivot point | 3500 mm |
| Max. tipping load* | 1900 kg |
| Max. breakout force / 50 cm | 2200 kg |
| Engine make and type | Kubota V2403 Stage 3B |
| Engine output (ECE R120) | 36 kW (49 hp) |
| Maximum torque | 156 Nm @ 1600 rpm |
| Fuel | diesel |
Pulling Force
| Wheel size | Drive speed | Pulling force |
| 380/55-17” TR | 26 km/h | 2100 kp |
Width
| Wheel size | Width |
| 380/55-17” TR | 1490 mm |
Height with cab
| Wheel size | 380/55 – 17 TR |
| ROPS | 2200 mm |
| GT Cab | 2230 mm |
Dimensions
Lift Capacity 1900 kg
Engine Power 57 hp
Lift Height 3.5 m
Speed 30 km/h
Specifications
| Length | 3395 mm |
|---|---|
| Width (with standard wheels) | 1490 mm |
| Height (with standard wheels) | 2200 mm |
| Weight | 2540 kg |
| Standard wheels | 380/55-17” TR |
| Transmission, drive | hydrostatic |
| Pulling force max. | 2100 kp |
| Drive speed max. | 30 km/h |
| Auxiliary hydraulics | 80 l/min 225 bar |
| Turning radius inside/outside | 1370 mm / 2990 mm |
| Lifting height to pivot point | 3500 mm |
| Max. tipping load* | 1900 kg |
| Max. breakout force / 50 cm | 2200 kg |
| Engine make and type | Kohler KDI 1903 TCR |
| Engine output (ECE R120) | 42 kW (57 hp) |
| Maximum torque | 225 Nm @ 1500 rpm |
| Fuel | Diesel |
Pulling Force
| Wheel size | Drive speed | Pulling force |
| 380/55-17” TR | 30 km/h | 2100 kp |
Width
| Wheel size | Width |
| 380/55-17” TR | 1490 mm |
Height With Cab
| Wheel size | 380/55 – 17 TR |
| ROPS | 2200 mm |
| GT Cab | 2230 mm |
Dimensions
